GFS-24R (Silent Type)

Generator Set Specifications
Model: GFS-24R (Silent Type)
Power Ratings:
- Prime Power: 30 KVA / 24 KW
- Standby Power: 33 KVA / 26.4 KW
Frequency/Speed: 60 Hz / 1800 rpm
Voltage: 380V (3 Phase, 4-wire connection)
Dimensions: 2250 x 860 x 1210 mm
Weight: 860 KGS

Engine Specifications
Model: ZH4100D-34KW
Cylinders: 4
Displacement: 3.61L
Fuel Consumption: 258.4 g/KW.h

Alternator Specifications
Model: UFIX-24KW
Insulation Class: H
Excitation Mode: Brushless
