ZH4105ZD-60KW

Generator Set Specifications
Model: ZH4105ZD-60KW
Aspiration Type: Turbocharged
Starting Method: 12V electric starter with battery charging alternator
Governor: Mechanical

Alternator Specifications
Model: UFIX-50KW
Insulation Class: H
Rated Power Factor: 8
Excitation Mode: Brushless
IP Class: IP23
Voltage Regulation: ±1.5% with 4% engine governing
Optional Model: UFIX6120N

Generator Set Specifications (GF-50R)
Type: Open
Prime Power: 62.5 kVA / 50 kW
Standby Power: 69 kVA / 55 kW
Frequency/Speed: 60 Hz / 1800 rpm
Standard Voltage: 380V (3 Phase, 4-wire connection)

Dimensions and Weights
Dimensions (L × W × H): 1740 × 800 × 1230 mm
Weight: 820 kg

Fuel Specifications
Displacement: 4.15 liters
Fuel Tank Capacity: 8 hours
Fuel Consumption: Less than 251.6g/kW.h
