Standard Clevis Hanger (SCH)

Standard Clevis Hanger (SCH) Specifications:
Usage: Supports insulated and non-insulated horizontal pipes.
Features: - Vertical adjustment capability. - Allows small horizontal movements without transferring them to the hanger rod.
Curved edges for easy handling and installation.
Pipe sleeve installed to prevent deformation under pipe weight (from 8" size and larger).
Size Range: Available from 3/4" (20 mm) to 30" (750 mm).
Material: Carbon steel (EN 10111 DDII), stainless steel available upon request.
Finish Options: Plain, zinc plating, or hot-dip galvanized.
Compliance: Meets MSS SP-69 & SP-58 Type 1, UL 203, and NFPA section 13.
